Magnetic Pumps

Magnetic Driven Chemical Process Pump

BURLY® CHEM PUMP INDUSTRIES is now on final stage in development of SEALLESS MAGNETIC DRIVE CHEMICAL PROCESS PUMP. We are expecting to offer the product to our customers in very near future.

BURLY® Seal less Magnetic Drive Chemical Process Pump will be in simple two piece all Polypropylene and Casting construction with GFT bush bearing requiring no lubrication. The pump will be 100% Leak Proof due to its magnetic driven arrangement. No shaft seal used which automatically will solve the problems of seal leakage. High power permanent magnets will ensure full power transfer and eliminates slippage.

All pumps are centrifugal type with semi-open impeller and need priming before startup.

The Pump model PCX™ - MD will be useful for :
  • Acid Transfer
  • Dyes
  • Solvents
  • Pharmaceuticals Industries
  • Food Processing Industries
  • Corrosive Chemicals
  • Electroplating
  • Galvanizing and Anodizing Plant
  • Kerosene
  • Petrol
  • Toxic and Fuming Liquids
Performance Data:
Pump Model In/Out
Size
Max.
Capacity
Max.
Head
H.P. Phase
PCX - 90MD 26 x26 mm
90 LPM
09 0.50 Single/Three
PCX-130MD 26 x26 mm 130 LPM 12 0.75 Single/Three
PCX-175MD 1”BSP ” 170 LPM 14 1.0 Three
PCX-300MD 1.5” x 1.25 280 LPM 20 1.5 Three
