PVDF-100 Pump |
These pump are recommended for high temperature fluid transfer.
- Due to thickness limitations of lined casing 4-5 mm, the PVDF wall gets worn out.
- In comparison to that SOLID mould PVDF of 12-14 mm which increases their life span.
- Outstanding chemical resistance.
- Very good mechanical strength and toughness.
- High abrasion resistance
|
|
|
|
- Physiologically harmless and approved for contact with food products.
- Continuous use temperature for up to 130º C.
- Excellent intrinsic fire resistance.
- Semi – open PVDF impeller reinforced by large metal inserts.
|
Sealing Options: |
- Externally Mounted Mechanical Seal
- Gland Packing
|
Performance Data: |
Model |
Suction
mm |
Delivery
mm |
Imp.Dia.
mm |
H.P. |
RPM |
Head in Mtr. / Cap. in M3 / hr. |
PVDF-100 |
25 |
25 |
100 |
1 |
2900 |
13 |
12 |
11 |
10 |
08 |
07 |
00 |
03 |
05 |
06 |
09 |
11 |
|
|
NOTE: Performance Applicable to Liquid of Specific Gravity 1 and Viscosity as of Water. |
|
|
